XR Elite Business Edition

In-box Items

VIVE XR headset

Battery cradle
Controller (L)
Controller (R)
Lanyards x 2
Microfiber Pouch
Top Strap
Type-C to Type-C Cable
Type-A to Type-C Cable x 2
Lens Protection Card
Documentation (QSG / Safety Guide / Warranty Card)

Headset Specs

Brief Highlights

1. Convertible and compact. It's a high-performance, all-in-one XR headset that transforms into a pair of portable immersive glasses.
   2. Features robust graphics performance and high-resolution, vivid passthrough capability in a remarkably small form factor.
   3. Personalize for a comfortable viewing experience with IPD (inter-pupillary distance) and diopter dials.

Resolution

1920*1920 pixels per eye (3840*1920 pixels combined)

Headset Tracking

6 DoF Inside-out Tracking

Refresh Rate

90 Hz

Field of view

Up to 110 degrees

Audio

Dual microphones for echo cancellation
Embedded speakers

Inputs

Dual integrated microphones
Volume button
Headset button

Processor

Qualcomm® Snapdragon™ XR2

Storage & Memory

128 GB / 12 GB

Connections

1x USB 3.2 Gen-1 Type-C peripheral port
1x USB 3.2 Gen-1 Type-C power port
Bluetooth 5.2 + BLE
Wi-Fi 6 + 6E ¹
1.Wi-Fi 6E support is country dependent. For more details, please refer to this link

Sensors

4x Tracking cameras
16 MP RGB camera
Depth sensor
G-sensor
Gyroscope
Proximity sensor

Ergonomics

Perfect weight balance provides comfortable long-session use
Ergonomically curved battery module mounted in the rear as counterweight
Magnetically-attached front gasket
Eye comfort adjustment accommodating IPD range of 54 to 73mm

Battery

26.6Wh Battery Cradle – removeable & hot-swappable
Lightweight and quickly rechargeable with Lithium-Polymer Gel chemistry
Designed and molded with an ergonomic curve

Microphone

Dual integrated microphones

IPD

Accommodates 54-73mm

Tracking

VIVE Inside-out Tracking
Up to 10x10m play space recommended

Controller Specs

Sensors

Hall sensors on Trigger and Grip buttons
Capacitive sensors on Trigger, Joystick, and Thumb-rest area
G-Sensor
Gyroscope

Input

Ergonomic Grip button
Analog Trigger button
AB / XY buttons
System / Menu buttons
Joystick

Battery

Up to 15 hours of battery life
Integrated rechargeable battery (charged via USB-C)
*All battery claim results will vary. Battery life and charge cycles vary by use

Tracked Area Requirements

Standing / Seated

Both available

Room-scale

Up to 10m x 10m play area recommended
Minimum play area is 1.5m x 1.5m (standing)
